Manufacturer:Allen-Bradley

Model:1746-OG16

Product Type:Digital Output Module

Number of Channels:16

Input Voltage:24 VDC

Output Voltage Range:5 - 24 VDC

Output Current per Channel:10 mA

Max Output Current:160 mA

Isolation Voltage:500 VDC

Temperature Range:-40°C to +70°C

Operating Humidity:5% to 95%

Enclosure Type:IP20 Open-Type

Connection Type:Backplane Connector

Mounting Type:Panel-Mounted

Power Consumption:1.5 W

    The AB 1746-OG16 Current Sinking TTL Output Module is engineered to deliver unparalleled reliability and precision in industrial automation applications. Its robust design ensures seamless integration into complex control systems, enhancing efficiency and operational safety.

    Featuring a wide operating voltage range and high current rating per channel, this module supports a variety of load types, making it suitable for diverse industrial settings. The conformal coated PCB protects against environmental contaminants, ensuring stable performance under harsh conditions.

    With its panel mount design, the 1746-OG16 is easy to integrate into existing systems, reducing installation time and complexity. The TTL compatible interface facilitates smooth communication with other system components, streamlining data exchange and control processes.

    Engineered with a focus on durability and reliability, this module is tested to withstand extreme temperatures, from -40°C to +70°C, ensuring consistent performance across various industrial environments. The use of high-quality materials further enhances its lifespan, minimizing maintenance requirements and downtime.

    The AB 1746-OG16 Current Sinking TTL Output Module is an essential component for achieving optimal control and efficiency in modern industrial automation systems. Its combination of advanced features, superior performance, and ease of integration makes it a preferred choice among engineers and technicians worldwide.
